Morimoto

07-13 Toyota Tundra 4Banger LED Fog Lights

07-13 Toyota Tundra 4Banger LED Fog Lights

Regular price $599.99 CAD
Regular price Sale price $599.99 CAD
Sale Sold out
Shipping calculated at checkout.
Quantity

Upgrade your vehicle’s fog lighting with the Morimoto 4Banger SAE-Compliant LED Fog Lights, engineered to deliver outstanding visibility, precise beam control, and dependable performance in demanding driving conditions.

Designed to meet the latest SAE F photometric standards, the 4Banger Wide Beam provides powerful, controlled illumination while minimizing glare for oncoming traffic. Available in both HXB and NCS configurations, the 4Banger allows you to choose the performance level that best suits your driving needs.

HXB Wide Beam – Maximum Performance

The 4Banger HXB Wide Beam takes fog-light performance to another level. Featuring high-output LEDs, the HXB version produces an exceptionally powerful and wide beam pattern while maintaining the controlled cutoff required for SAE-compliant road use.

With approximately 80% more intensity than competing SAE-compliant fog lights, the HXB Wide Beam is ideal for drivers looking for maximum usable light output without sacrificing beam control.

NCS Wide Beam – Controlled & Efficient

The 4Banger NCS Wide Beam uses premium Nichia LEDs to produce a wide, evenly distributed beam with excellent vertical gradient control.

Designed specifically for effective on-road fog-light performance, the NCS optic delivers strong foreground and roadside illumination while keeping glare under control for approaching drivers.

FEATURES & BENEFITS

SAE-Compliant Performance: Engineered to meet SAE F photometric requirements for controlled on-road fog-light use.

HXB High-Output Option: Delivers up to 80% more intensity than competing SAE-compliant fog lights for exceptional visibility.

NCS Wide Beam Option: Premium Nichia LEDs provide a broad, controlled beam with excellent vertical gradient and glare management.

White or Yellow Output: Choose the output color that best matches your driving conditions, vehicle style, and personal preference.

Fully Adjustable: Precision mounting brackets allow the beam to be properly aimed for maximum usable illumination.

Efficient Air Cooling: Integrated cooling technology helps regulate operating temperatures and maintain consistent LED performance.

All-Weather Construction: Built to perform reliably through rain, snow, fog, dirt, and harsh driving environments.

Premium Morimoto Engineering: High-quality optics, LEDs, housings, and mounting hardware are designed for long-lasting performance.

Upgrade to the Morimoto 4Banger SAE-Compliant Fog Lights for an OEM+ appearance combined with serious lighting performance, excellent beam control, and increased visibility when conditions get tough.

Technical Specifications

  • Intensity: 14,700 Cd (@20 Min. / 21C Ambient) (147lux @ 10m)
  • Input: Proprietary Overmolded Deutsch DT 2-Pin w/ Pigtail
  • Input Voltage: 9-18V DC
  • Power: 42w
  • Current: 3.2A @ 13.2V DC
  • Dimensions: 82mm W, 67mm H, 60mm D
  • Color: 2700K
  • Light Source: 3x Osram HX Boost (5700K)
  • Material: Makrolon LED PC (Lens), Powdercoated Die Cast Aluminum (Housing)
  • IP Rating: IP68K (Dust / High Pressure Water Resistant)

What's Included

  • Fog Light Brackets: 2x (One Pair) Morimoto 4Banger (BAF019 / Type T2 Style)
  • LED Pods: 2x (One Pair) Morimoto 4Banger (HXB Yellow SAE Wide Beam - BAF012)
  • Hardware: Complete Pack (Stainless Steel)
  • Wiring: Plug N Play Connection Kit
  • Warranty: Limited Lifetime

Compatibility

  • TOYOTA TUNDRA: 2007-2013
  • REPLACES TOYOTA PART #: 81210-AA030
  • Note: Vehicle must have OEM Halogen Fog lights
  • 4Banger COMPLIANCE: Wide beam photometrics are SAE F 20 compliant
